Vacuum Ejector, Inline, Body, 3/8 BSPT MPN:ZH20DLA-03-04-04
Vacuum Ejector, Inline, Body, 3/8 BSPT
The SMC Vacuum Ejector is a reliable and efficient inline solution for various industrial applications. Its high flow rate of 135 lpm and maximum operating temperature of 60°C make it suitable for use in a range of environments. The ejector's compact design, measuring 151.1mm in length and 26.5mm in width, allows for easy integration into existing systems. Ideal for use in pneumatic conveying, material handling, and vacuum systems, this ejector provides consistent performance and helps to reduce system pressure. Its durable construction and long lifespan ensure reliable operation and minimize maintenance requirements.
Top product features:
- Vacuum Ejector with a maximum flow rate of 135 lpm
- Exhaust port with a size of 1/2 in and type BSPT
- Vacuum port with a size of 1/2 in and type BSPT
Top product applications:
- Vacuum Ejector can be used in a manufacturing process to remove excess material from a product.
- Vacuum Ejector can be used in a laboratory setting to remove waste from a piece of equipment.
- Vacuum Ejector can be used in a medical device to remove bodily fluids or tissues.
Item Vacuum Ejector, Exhaust Port Size 1/2 in, Exhaust Port Type BSPT, Maximum Flow Rate 135 lpm, Maximum Operating Temperature 60 Degrees C, Maximum Supply Pressure 87 psi, Overall Length 151.1 mm, Overall Width 26.5 mm, Pressure Port Size 3/8 in, Pressure Port Type BSPT, Series ZH, Vacuum Port Size 1/2 in, Vacuum Port Type BSPT, Vacuum Pressure @ 40 PSI -30 kPa, Vacuum Pressure @ 75 PSI -53 kPa, Weight 95 g
Additional Information
- Country of Origin: JP
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 2.70
- Package Height: 1.10
- Package Weight: 0.25
Product info last updated on January 14, 2026 12:13pm UTC
Category: Compressors, Air Tanks and Pneumatic Parts
