Digital Panel Meter, DC Current MPN:H335-1-22-020
Digital Panel Meter, DC Current
The Simpson Digital Panel Meter is a reliable and accurate solution for measuring DC current in a variety of applications. With a high-precision display and True RMS measurement capability, this meter provides reliable readings in a range of environments. Its compact 1/8 DIN size and screw terminal connections make it easy to integrate into existing systems. Suitable for use in industrial, commercial, and medical settings, this meter offers a range of benefits, including improved accuracy, increased efficiency, and reduced maintenance costs. Its rugged design and NEMA rating ensure it can withstand harsh conditions, making it an ideal choice for demanding applications.
Top product features:
- True RMS measurement
- Red LED display with 3-1/2 digits
- Two SPDT relays rated 5 Amps @ 250V AC
Top product applications:
- Current measurement in industrial control systems
- DC power supply monitoring in electronic equipment
- Automotive electrical system testing and diagnosis
Digital Panel Meter, DC Current, Input Range 0 to 2mA DC, Accuracy +/-0.2 Percent of Reading +/-2 Count, Display Span 1999, Display Digits 3-1/2, Red LED Display, Two SPDT rated 5 Amps @ 250V AC Relays, True RMS -, No Excitation, Use With -, Fits 1/8 DIN Cutout, Connector Type Screw Terminal, Process Connection -, Power Required 120V AC, RS-485 Interface, Output -, - NEMA Rating, Depth 3.25 in, Mounting Clip, Style Hawk 3, Includes Instructions, Manufacturers Warranty Length 2 yr
Additional Information
- Country of Origin: US
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 6 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 7.00
- Package Width: 2.20
- Package Height: 4.30
- Package Weight: 1.00
Product info last updated on February 19, 2026 11:16am UTC
Category: Process Monitoring
