Enclosed Power Relay, 240VAC, DPDT, Pins MPN:3TX7131-4DH13
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G8523847
Enclosed Power Relay, 240VAC, DPDT, Pins
This enclosed power relay from Siemens is a reliable and efficient solution for high-current applications. With a DPDT contact form and 30A current rating, it can handle demanding tasks such as controlling motor starters, lighting systems, and HVAC equipment. Its 240VAC coil voltage and 3hp horsepower rating make it suitable for a wide range of industrial and commercial applications. The relay's compact design, measuring 1.35 x 1.18 x 2.04 inches, makes it easy to integrate into DIN rail and top flange mounting systems, providing a durable and space-saving solution for automation and control systems.
Top product features:
- Enclosed design provides protection for the relay and surrounding components
- DPDT contact form allows for two separate control circuits to be switched independently
- Silver alloy contact material ensures reliable and durable switching performance
Top product applications:
- Motor Control Circuits
- Industrial Automation Systems
- High-Current Power Distribution Systems
Enclosed Power Relay, Coil Voltage 240V AC, Contact Form DPDT, Current Rating 30 A, Status Indicator No Indicator, Contact Rating (AC) 30 A @ 240V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC 3 hp, Mounting Style DIN Rail & Top Flange, Body Depth 1.35 in, Body Height 1.18 in, Body Width 2.04 in, Contact Material Silver Alloy, Dielectric Strength 1,500 Vrms Between Contacts, 2,000Vrms Between Poles, 4,000Vrms Between Coil and Contact, Electrical Operating Durability 100,000
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 75 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 0.03
- Package Width: 0.03
- Package Height: 0.05
- Package Weight: 0.20
Product info last updated on February 2, 2026 1:59pm UTC
Category: Industrial Electrical Controls and Automation
