IEC Magnetic Contactor, 1NC, 220V-240V AC, 3 P, Non-Reversing, Screw MPN:3RT20151AP62

• Siemens IEC Magnetic Contactor is an electrically operated switching device rated for operation within IEC standard specifications.

  - Coil voltage: 220-240 V AC

• - Poles / main contacts: 3-pole with 3 normally open main contacts
• - Auxiliary contacts: 1 NC
• - Reversing: No (Non-Reversing)
• - Auxiliary contact configuration / form: 1NC
• - Electrical connection: Screws
• - Mounting: DIN Rail, Surface
• Mounting position: Vertical
• - Frame / Series / Code: S00
• Frame Size: S00
• Series: SIRIUS 3RT20
• - Enclosure / IP rating: provided without an enclosure
• suitable for use in environments compliant with IP20 ratings
• - Maximum voltage rating: rated for operation up to 690V AC within specified conditions
• - Frequency: 50/60 Hz
• - Full load amps: 7 A inductive
• 18 A resistive
• - Mechanical durability: tested for a mechanical lifespan of approximately 30 million cycles under specified testing conditions
• - Dimensions: Depth 2.87 in
• Height 3.08 in
• Width 1.97 in
• - Operating temperature: -13°F to 140°F
• - Embedded surge suppressor: No
