IEC Magnetic Contactor, 2NC, 110V-120V AC, 3 P, Reversing, Screw MPN:3RA23168XB301AK6

• The Siemens IEC Magnetic Contactor is a 3-pole, reversing-type control device rated for operation within the specified voltage and current ranges. The device has screw terminals

• complies with relevant standards
• operates at a coil voltage of 110–120 V AC
• includes three main contacts (normally open) and two auxiliary contacts (normally closed)
• IP20 enclosure rating and vertical mounting orientation (DIN Rail or Surface). Supports auxiliary contact functionality as specified.

  Key features

• - Action: Reversing action capability as specified.
• - Poles/Main contacts: 3 poles
• 3 normally open
• 2 normally closed
• - Auxiliary contacts: 2 NC
• - Coil voltage: 110–120 V AC
• Frequency: 50/60 Hz
• - Maximum voltage: Rated for use up to 690 V AC under normal operating conditions
• - IP rating: IP20
• - Enclosure: No Enclosure
• Standards: REACH Art 33, WEEE
• - Mounting: Vertical
• Mounting style: DIN Rail, Surface
• Terminals: Screw
• - Series/Frame: SIRIUS 3RA23, Frame size S00
• - Mechanical durability: 10,000,000 cycles
• Temperature: -13°F to 140°F
• - Dimensions: Width 3.54 in, Height 3.20 in, Depth 3.70 in
• - Phase: Three
• Reversing: Yes
