Miniature Circuit Breaker, BQ Series, 100A, 3 Pole, 240V AC, 10kA at 240V AC MPN:BQ3B10000S01
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2614464
Miniature Circuit Breaker, BQ Series, 100A, 3 Pole, 240V AC, 10kA at 240V AC
The Siemens BQ Series 100A 3-Pole Miniature Circuit Breaker is a reliable and efficient solution for protecting electrical panels and equipment. Designed for use with Siemens panelboards, this circuit breaker features a shunt trip mechanism and a maximum air rating of 10kA at 240V AC. Its compact size and bolt-on mounting style make it easy to install and integrate into existing systems. Ideal for use in commercial and industrial settings, this circuit breaker provides enhanced safety and reliability, reducing the risk of electrical shock and equipment damage. Its long lifespan and minimal maintenance requirements make it a cost-effective solution for a wide range of applications.
Top product features:
- Trips on overload or short circuit
- Protects against electrical shock
- Shuts off power to the circuit in case of a fault
Top product applications:
- Industrial Power Distribution Systems
- Commercial Building Electrical Systems
- Electrical Panelboards and Switchgear
Miniature Circuit Breaker, Amps 100 A, AC Voltage Rating 240V AC, Circuit Breaker Type Shunt Trip, Number of Poles 3, DC Voltage Rating Not Rated, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style Bolt On, Phase Three, Series BQ, Max. AIR Rating 10kA at 240V AC, For Use With Siemens Panelboards, Terminal Connection Lug, Frame Size 125A/BQ, Length 4 in, Width 4 in, Depth 5 in, Max. Operating Temp. 104 Degrees F, Min. Wire Size 2 AWG (Al), 4 AWG (Cu), Max. Wire Size 1/0 AWG
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 25 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 5.50
- Package Width: 4.40
- Package Height: 3.70
- Package Weight: 1.48
Product info last updated on January 13, 2026 12:00pm UTC
Category: Circuit Protection
