Molded Case Circuit Breaker, ED4 Series, 90A, 1 Pole, 120/277V AC, 22kA at 277V AC MPN:ED41B090
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G0119531
Molded Case Circuit Breaker, ED4 Series, 90A, 1 Pole, 120/277V AC, 22kA at 277V AC
Protect your electrical systems with the ED4 Series Molded Case Circuit Breaker from Siemens. Designed for use with SB Switchboards and Sentron Panelboards, this 90A circuit breaker offers high amp trip settings and thermal magnetic trip types for reliable protection. Suitable for 120/277V AC applications, it provides 22kA at 277V AC for added safety. Ideal for a range of industries, including commercial and industrial settings, this circuit breaker ensures efficient and safe electrical operation. Its compact design and lug-in panelboard mounting style make it easy to integrate into your existing systems, providing peace of mind for your electrical infrastructure.
Top product features:
- 90A High Amp Trip Setting
- Thermal Magnetic Trip Type
- Single Phase Connection Capability
Top product applications:
- Industrial electrical panelboards
- Commercial switchboards
- Utility substations
Molded Case Circuit Breaker, 90 A Amps, AC Voltage Rating 120/277V AC, Max. AIR Rating 22kA at 277V AC, For Use With SB Switchboards, Sentron Panelboards, Series ED4, High Amp Trip Setting 90 A, Low Amp Trip Setting 90 A, Circuit Breaker Type Standard, Number of Poles 1, DC Voltage Rating 125V DC, Terminal Connection Load Side Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Fixed, Phase Connection Any, Frame Size 125A/ED, Circuit Breaker Mounting Style Lug In Panelboard
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 40 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.00
- Package Width: 1.00
- Package Height: 5.00
- Package Weight: 1.30
Product info last updated on January 10, 2026 3:17pm UTC
Category: Circuit Protection
