Check Valve, 2483SC Series, Inline Swing, 1/2 in NPSM FNPSM, 316L Stainless Steel MPN:4371001740
Check Valve, 2483SC Series, Inline Swing, 1/2 in NPSM FNPSM, 316L Stainless Steel
SHARPE 4371001740 is a 1/2 in. inline swing check valve with female NPSM threaded connections on both ends. This self-acting 2-way valve allows flow in one direction and closes in response to reverse flow in steam and process piping systems. The stainless steel body and internal 316 stainless steel components are specified for corrosive, flammable media, and toxic service applications.
Key Features:
- Valve type: Inline swing check valve
- Body material: 316L stainless steel
- Check mechanism material: 316 stainless steel
- Connection size: 1/2 in. x 1/2 in.
- Connection type: Female NPSM threaded x female NPSM threaded
- Maximum operating pressure: 1,215 psi
- Maximum temperature: 300 degrees F
- Media: Steam
- Seal material: 304 stainless steel and graphite
- Seat material: Metal
- Mounting orientation: Horizontal or vertical
- Overall length: 3.11 in.
- Cv: 9
- Standards: API 602, NACE MR0175
- Valve series: 2483SC
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.11
- Package Width: 2.15
- Package Height: 3.25
- Package Weight: 3.30
Product info last updated on February 25, 2026 6:20am UTC
Category: Pipes, Valves and Fittings
