Check Valve, 2027 Series, Inline Swing, 1 in, Socket Weld x Socket Weld, 316 Stainless Steel MPN:4371000340
Check Valve, 2027 Series, Inline Swing, 1 in, Socket Weld x Socket Weld, 316 Stainless Steel
SHARPE 4371000340 is a 1 in inline swing check valve configured with an inline swing check mechanism for one-way flow applications in steam and process piping systems. It is listed for corrosive, flammable, toxic, and general process piping service
- verify compatibility with the system media, pressure, and temperature ratings before use. The valve features a 316 stainless steel body, a 316 stainless steel check mechanism, PTFE seal material, a metal seat, and horizontal or vertical mounting.
Key Features:
- Inline swing check mechanism for one-way flow control
- 1 in nominal valve size and 1 in pipe or tube size
- 316 stainless steel body and 316 stainless steel check mechanism
- Socket weld x socket weld connections with 1 in connection size on both sides
- Female connections on both sides
- NPSM listed on side 1 and side 2
- Maximum steam pressure: 125 psi WSP
- Maximum operating temperature: 350 degrees F
- Inline body style with 2-way valve configuration
- Horizontal or vertical mounting orientation
- Overall length: 3.51 in
- Meets MSS SP-110
- Valve series: 2027
- Standard silent check
- no counterweight
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.80
- Package Width: 3.50
- Package Height: 2.10
- Package Weight: 1.64
Product info last updated on February 24, 2026 11:27am UTC
Category: Pipes, Valves and Fittings
