IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 4 P, Spring Type MPN:LC1G4004BEEA
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient device for controlling electrical circuits in various applications. With its 24-48V AC/DC coil voltage and 4-pole design, it's suitable for single-phase systems. The spring-type terminals ensure secure connections, while the 1NC/1NO auxiliary contacts provide flexible control options. Rated for 8 million cycles, this contactor withstands heavy use in industrial environments. Suitable for applications such as lighting control, HVAC systems, and power distribution, it provides IP20 protection and operates within a wide temperature range. Its compact design and high durability make it an ideal choice for a variety of industries.
Top product features:
- The product has a 4-pole, single-phase configuration.
- It includes auxiliary contacts configured as 1NC/1NO.
- The contactor uses spring-type terminals.
Top product applications:
- Industrial Automation Control Systems
- Power Distribution Panels
- Machine Tools and Manufacturing Equipment
The item is an IEC Magnetic Contactor from Schneider Electric (TeSys Giga series). It is a 4-pole, single-phase device with a 24–48 V coil voltage (AC/DC) and includes auxiliary contacts configured as 1NC/1NO (2 total). The contactor uses spring-type terminals and is rated for operation within the specified voltage ranges. It carries IP20 protection, mounts on a plate, and operates within a -13 °F to 140 °F temperature range. Its mechanical durability is rated at 8,000,000 cycles. The unit does not include an embedded surge suppressor.
Key features
- - Coil voltage: 24–48 V AC/DC
- - Poles: 4
- - Auxiliary contacts: 2 total (1NC/1NO)
- - Terminal connection type: Spring Type
- - Mounting style: Plate
- - IP rating: IP20
- - Frequency: 50/60 Hz
- - Maximum voltage rating: 1000V AC
- - Full-load current: Inductive 490 A
- Resistive 550 A
- - Operating temperature: -13 °F to 140 °F
- - Embedded surge suppressor: No
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Item: IEC Magnetic Contactor
- - Phase: Single
- - Overall dimensions: Depth 4.8 in
- Height 11.42 in
- Width 7.28 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 63 days
- Minimum Order Quantity: 4
- Unit of Measure: EA
- Package Length: 14.57
- Package Width: 10.04
- Package Height: 11.93
- Package Weight: 22.05
