IEC Magnetic Contactor, 1NC/1NO, 100V-250V AC/DC, 3 P, Spring Type MPN:LC1G500KUEN
Free Shipping
In Stock
The Schneider IEC Magnetic Contactor is a reliable and efficient switching device designed for single-phase power circuit control. Suitable for use in a variety of applications, including industrial automation, HVAC systems, and lighting control, this contactor is rated for operation within a wide voltage range and features a durable spring-type terminal connection. Its compact IP20 enclosure and high current capacity make it an ideal choice for demanding applications. With a mechanical lifespan based on standard testing procedures and a temperature range of -13°F to 140°F, this contactor provides reliable performance in a wide range of environments.
Top product features:
- Operates within a wide voltage range of 100V-250V AC/DC
- Has 3 poles with 2 auxiliary contacts (1NC/1NO) for controlling power circuits
- Designed for single-phase operation with an expected mechanical lifespan based on standard testing procedures
Top product applications:
- Motor Control Circuits
- Industrial Automation Systems
- Electrical Panel Control
The IEC Magnetic Contactor is an electrically operated switching device used to control power circuits in accordance with IEC standards. It is a 3-pole device with 2 auxiliary contacts (1NC/1NO), wired with spring-type terminals, and coil voltage rated for operation within the specified voltage ranges. It belongs to the TeSys Giga series, has an IP20 enclosure, and rated for use up to 1000V AC in accordance with applicable standards. It is designed for single-phase operation and has an expected mechanical lifespan based on standard testing procedures, and is designed to operate within the specified temperature range (-13°F to 140°F).
- Auxiliary contacts: 2 total (1NC/1NO)
- Includes auxiliary contacts: Yes
- - Coil Voltage: 100V-250V AC/DC
- - Contactor Style: IEC
- - Embedded Surge Suppressor: No
- - Frequency: 50/60 Hz
- - Full Load Current – Inductive: 630 A
- Full Load Current – Resistive: 700 A
- - IP Rating: IP20
- - Mounting Style: Plate
- - Terminal Connection Type: Spring Type
- - Phase: Single
- - Number of Poles: 3
- - Maximum Voltage Rating: 1000V AC in accordance with applicable standards
- - Maximum Operating Temperature: 140 Degrees F
- - Minimum Operating Temperature: -13 Degrees F
- - Mechanical Operating Durability: Has an expected mechanical lifespan based on standard testing procedures
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 7 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.20
- Package Width: 8.86
- Package Height: 12.20
- Package Weight: 17.55
