Socket, Relay, Square, 15 A, 11 Pins, Quick Connect MPN:8501RSD43P14V53
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G908536684
Socket, Relay, Square, 15 A, 11 Pins, Quick Connect
The Schneider Square Relay is a versatile and reliable solution for a wide range of applications, including industrial automation, control systems, and power distribution. With a 15A current rating and 11-pin quick-connect design, this relay offers efficient and convenient connections. Its 3PDT contact form ensures high switching accuracy and durability, while the LED indicator and mechanical flag provide clear status monitoring. Suitable for use in various voltage and current configurations, this relay is ideal for applications such as motor control, lighting systems, and HVAC control, and can handle up to 1/2 horsepower at 120V AC and 1 horsepower at 240V AC.
Top product features:
- Relay coil voltage is 24V DC
- Contact form is 3PDT
- Has a status indicator LED
Top product applications:
- Industrial Automation Systems
- Automotive Electronics
- Medical Device Control Panels
Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form 3PDT, Current Rating 15 A, Electrical Connection Quick-Connect, Flat Pin Width 0.18 in, Number of Pins 11, Pin Shape Flat, Sealing Enclosed, Status Indicator LED Indicator, Mechanical Flag, Contact Rating (AC) 1.5 A @ 240V, 10 A @ 120V, 3 A @ 120V, 7 A @ 277V, Contact Rating (DC) 10 A @ 28V, Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.4 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 57 days
- Minimum Order Quantity: 25
- Unit of Measure: EA
- Package Length: 1.39
- Package Width: 0.00
- Package Height: 2.18
- Package Weight: 0.13
Product info last updated on February 22, 2026 4:39am UTC
Category: Industrial Electrical Controls and Automation
