IEC Miniature Magnetic Contactor, 1NC, 120V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0901F7

• Schneider Electric IEC Miniature Magnetic Contactor is a 3-pole, 120 V AC coil device rated for controlling circuits within specified load parameters

• compatible with IEC-standard control systems.

  - Coil voltage: 120 V AC

• - Action: Non-Reversing
• - Poles: 3
• - Main contacts: 3 normally open
• - Auxiliary contacts: 1 NC
• - Includes auxiliary contacts: Yes
• - Termination: Screw Clamp terminals
• - Mounting: DIN Rail, Plate
• Mounts On: Plate, Rail
• - Enclosure: No Enclosure
• IP22
• - Maximum voltage rating: 690 V AC
• - Frequency: 50/60 Hz
• - Full load amps: 20 A (resistive)
• 9 A (inductive)
• - Mechanical durability: 10 Mcycles
• - Electrical durability: 1,300,000 cycles
• - Series: TeSys K
• - Dimensions: Depth 1.97 in
• Height 1.73 in
• Width 1.77 in
• - Net weight: 0.18 kg
• - Rated making capacity: 110 A
• - Inrush VA: 30 VA
• - Hold VA: 4.5 VA
