IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type MPN:LC1G8004EHEN

• The item is an IEC magnetic contactor. It is rated for operation within the specified IEC standards. It incorporates electromagnetic switching components suitable for controlling motors, lighting, and other industrial loads within specified parameters. This unit is a 4-pole device with a 48-130 V AC/DC coil, plate mounting, and spring-type terminals. It includes two auxiliary contacts configured as 1NC/1NO.

  Key features:

  • - Coil voltage: 48-130 V AC/DC
  • - Poles: 4
  • - Mounting: Plate
  • - Terminal connection: Spring Type
  • - Rated for a maximum voltage of 1000 V AC according to specifications
  • - Frequency: 50/60 Hz
  • - IP rating: IP20
  • - Operates within the specified temperature range of -13°F to 140°F
  • - Has a mechanical endurance rating of up to 5,000,000 cycles under normal operating conditions
  • - Auxiliary contacts: 2 (1NC/1NO), includes auxiliary contacts
  • - Does not include built-in surge suppression features
  • external measures may be necessary for surge protection
  • - Full load amps (inductive): 900 A
  • - Full load current (inductive): 800 A
  • - Full load amps (resistive): 1,050 A
  • - Full load current (resistive): 1,050 A
  • - Phase: Single
  • - Series: TeSys Giga
  • - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
  • - Overall dimensions: 11.06 in W x 11.18 in H x 10.47 in D
