IEC Magnetic Contactor, 1NC/1NO, 100V-250V AC/DC, 3 P, Spring Type MPN:LC1G400KUEN
Free Shipping
In Stock
The Schneider IEC Magnetic Contactor is a reliable and efficient solution for switching power circuits in single-phase electrical systems. Its 3-pole design and 100-250V AC/DC coil voltage make it suitable for a wide range of applications, from industrial control panels to commercial lighting systems. With its spring-type terminals and IP20 enclosure rating, this contactor provides secure and durable connections. Its mechanical endurance and operating temperature range ensure reliable performance in various environments. Ideal for use in applications such as HVAC systems, conveyor belts, and pumps, this contactor offers a cost-effective and efficient solution for power switching needs.
Top product features:
- IEC Magnetic Contactor switches power circuits in accordance with IEC standards.
- It has 2 auxiliary contacts, 1 normally closed and 1 normally open.
- It operates within a specified voltage range of 100–250V AC/DC.
Top product applications:
- Industrial control systems
- Automation and robotics
- Power distribution and control panels
This item is an IEC Magnetic Contactor used to switch power circuits in accordance with IEC standards. It is a 3-pole device with 2 auxiliary contacts (1 normally closed and 1 normally open) and a coil voltage of 100–250V AC/DC. It uses spring-type terminals and is part of the TeSys Giga series, rated for operation within the specified voltage ranges and IP20 enclosure rating. It is intended for use in single-phase electrical systems and has the specified mechanical endurance based on testing standards, with an operating temperature range from -13°F to 140°F.
- Auxiliary contacts: 2 (1NC/1NO)
- - Coil voltage: 100–250V AC/DC
- - Poles: 3
- - Phase: Single
- - Mounting: Plate
- - Terminal connection: Spring Type
- - Maximum voltage rating: 1000V AC
- - Frequency: 50/60 Hz
- - IP rating: IP20
- - Mechanical durability: specified mechanical endurance based on testing standards
- - Operating temperature: -13°F to 140°F
- - Dimensions: Depth 4.8 in
- Height 8.86 in
- Width 5.51 in
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Full Load Amps — Inductive: 490 A
- - Full Load Amps — Resistive: 550 A
- - Full Load Current — Inductive: 400 A
- - Full Load Current — Resistive: 550 A
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 8.86
- Package Width: 12.20
- Package Height: 12.20
- Package Weight: 17.04
