IEC Magnetic Contactor, 1NC/1NO, 100V-250V AC/DC, 4 P, Spring Type MPN:LC1G1854KUEN

• The Schneider Electric IEC Magnetic Contactor is a 4-pole, electrically operated switching device rated for use in IEC-standard panels as specified. It uses an electromagnetic coil to open and close contacts and features 1NC/1NO auxiliary contacts with spring-type terminals. This IEC-style contactor is suitable for installation within control panel configurations as specified and is listed under the TeSys Giga series, rated for operation within the specified single-phase parameters.

  - Auxiliary contacts: 2 total (1NC/1NO)

• - Coil voltage: 100–250 V AC/DC
• - Poles/phase: 4 poles, Single phase
• - Terminal connection: Spring Type
• - IP rating: IP20
• - Maximum voltage rating: 1000 V AC
• - Frequency: 50/60 Hz
• - Full load current: rated for maximum full load currents of up to 185 A (inductive) and 305 A (resistive) under specified conditions
• - Full load amps: Inductive 250 A
• Resistive 305 A
• - Mechanical durability: tested to withstand up to approximately 8 million operational cycles under normal usage conditions
• - Operating temperature: designed to operate within a temperature range of -13°F to 140°F as specified
• - Mounting: Plate
• - Dimensions: 7.6 in (H) x 7.6 in (D) x 5.63 in (W)
• - Series: TeSys Giga
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
