IEC Magnetic Contactor, 1NC/1NO, 24V DC, 3 P, Non-Reversing, Screw Clamp MPN:LC1D65ABBE

• The IEC Magnetic Contactor is an electrically operated switching device rated for operation within specified motor control and resistive-load applications. It is a 3-pole, non-reversing unit with a 24 V DC coil and a 1 normally open/1 normally closed auxiliary contact configuration. Compatible with screw clamp terminals for control circuits and EverLink power connections within specified parameters, and it conforms to IEC standards

• designed according to TeSys Deca Green series specifications.

  - Coil voltage: 24 V DC

• - Poles / Auxiliary contacts: 3 poles
• 2 auxiliary contacts (1NO/1NC)
• - Reversing: Non-Reversing
• - Contactor style / series: IEC
• TeSys Deca Green
• - Rated voltage / frequency: rated for operation at voltages up to 690 V AC, 50/60 Hz frequency range
• - Full load amps: rated for full load currents of up to 80 A resistive, 65 A inductive within specified conditions
• - Rated making capacity: rated making capacity based on specified test conditions
• actual performance may vary depending on application conditions
• - Short-time withstand current: capable of withstanding short-term current surges as specified
• actual performance depends on operating environment
• - Durability (mechanical / electrical): mechanical/electrical durability ratings under standard testing conditions
• real-world lifespan may vary based on usage patterns
• - Electrical connections: Control Circuit—Screw Clamp
• Power Circuit—EverLink BTR Screw Connectors
• - Includes / protection: Everlink Power Connections
• Includes Auxiliary Contacts
• Includes Protective Cover
• - Environmental / rating: complies with IP20 environmental rating, pollution degree classification, and fire safety standards per UL94 V1
• - Standards: CCC, CSA, CSA C22.2 No 60947-4-1, DNV-GL, EAC, EN/IEC 60947-4-1, EN/IEC 60947-5-1, IEC 60335-1, KC, LROS, UKCA, UL Listed, UL 60947-4-1
• - Dimensions / weight: Net weight 1.002 kg
• Height 4.8 in
• Width 2.17 in
• Depth 4.72 in
• - Operating characteristics: Non-overlap time 1.5 ms
• Operating times: 55–65 ms (Closing), 20–120 ms (Opening)
• - Environmental / operating: Impulse withstand voltage 6 kV
• Signalling circuit frequency 25–400 Hz
• 5 mA switching current
• 17 V signalling voltage
• - Mounting / installation: DIN Rail, Plate mounting
• Mounts on Plate, Rail
• - Working height: Up to 9842.52 ft
• - Phase: Three
• - Max / operating temperature: Max. temp 850°C
• Max operating temperature 140°F
