IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type MPN:LC1G2254EHEA
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient solution for controlling power circuits in IEC-based control systems. With a wide voltage range of 48-130V AC/DC and 4-pole operation, it provides flexibility and scalability for various applications. Its spring-type terminals and compact design make it easy to install and integrate into existing systems. Suitable for use in industrial automation, manufacturing, and other high-reliability environments, this contactor offers improved safety and reduced maintenance costs. Its durable design withstands up to 8 million cycles and operates within a wide temperature range, ensuring consistent performance and minimizing downtime.
Top product features:
- The product has 2 auxiliary contacts with configuration options.
- It is rated for coil voltages between 48V and 130V AC/DC.
- It has an enclosure rating of IP20 per applicable standards.
Top product applications:
- Industrial Automation Systems
- Control Panels and Power Distribution Units
- Machine Control Systems
The SCHNEIDER ELECTRIC IEC Magnetic Contactor is a 4-pole, coil-operated switching device used to control power circuits in IEC-based control systems within specified parameters. It includes auxiliary contacts with configuration options as specified, and rated for coil voltages between 48V and 130V (AC/DC). The unit is compatible with mounting on plates using spring-type terminals and is part of the TeSys Giga series. It is rated for operation within the specified voltage ranges and has an enclosure rating of IP20 per applicable standards.
- Auxiliary contacts: 2 (configuration options as specified)
- - Coil voltage: 48-130 V AC/DC
- - Poles: 4
- Phase: Single
- - Mounting: Plate
- Terminal connection: Spring Type
- - Voltage rating: 1000 V AC
- - Enclosure rating: IP20 per applicable standards
- - Frequency: 50/60 Hz
- - Full load current (inductive/resistive): 225 A / 330 A
- - Full load amps (inductive/resistive): 290 A / 330 A
- - Mechanical operating durability: 8,000,000 cycles
- - Operating temperature: -13 to 140 °F
- - Overall dimensions: 5.63 in W × 10.04 in H × 7.6 in D
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Embedded surge suppressor: No
- - Includes auxiliary contacts: Yes
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 56 days
- Minimum Order Quantity: 6
- Unit of Measure: EA
- Package Length: 15.35
- Package Width: 10.43
- Package Height: 9.84
- Package Weight: 14.02
