Overload Relay, 1NC/1NO, 17 A Min current, 24 A Max current, 690V AC MPN:LRD22L
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G5383086
Overload Relay, 1NC/1NO, 17 A Min current, 24 A Max current, 690V AC
The Schneider Overload Relay provides reliable thermal protection for motors and other equipment in a wide range of applications. Suitable for use in industrial settings, it offers adjustable current settings from 17 to 24 amps and a maximum voltage rating of 690V AC. The relay features a compact design, direct mounting to contactors, and screw clamp terminals for easy installation. Its auto-reset and manual reset capabilities ensure seamless operation and troubleshooting. Ideal for use in manufacturing, power generation, and other high-demand environments, this overload relay helps prevent equipment damage and downtime, ensuring optimal system performance and efficiency.
Top product features:
- 1NC/1NO contact form provides a direct connection path for auxiliary circuit control.
- Minimum current setting of 17 A provides overload protection for low-power applications.
- Maximum current setting of 24 A allows for high-power applications to be protected.
Top product applications:
- Motor protection in industrial machinery
- Protecting electrical panels in commercial buildings
- Overcurrent protection in power distribution systems
Overload Relay, Auxiliary Contact Form 1NO/1NC, Maximum Overload Relay Current Setting 24 A, Minimum Overload Relay Current Setting 17 A, Trip Class 20, Maximum Voltage Rating 690V AC, NEMA Size Not Applicable, Number of Poles 3, Reset Type Auto, Manual, Mounting Style Direct To Contactor, Terminal Connection Type Screw Clamp Terminals, Compatible with Series TeSys Deca, Relay Style IEC, Overload Protection Type Thermal
Additional Information
- Country of Origin: TH
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.25
- Package Width: 3.56
- Package Height: 1.88
- Package Weight: 0.40
Product info last updated on February 18, 2026 6:53am UTC
Category: Industrial Electrical Controls and Automation
