IEC Miniature Magnetic Contactor, 2NC, 120V AC, 3 P, Reversing, Screw Clamp MPN:LC2K0901G7
Free Shipping
In Stock
The IEC Miniature Magnetic Contactor from Schneider is a versatile 3-pole reversing contactor ideal for motor control and resistive loads in various industrial applications. Its compact design and DIN rail or plate mounting options make it suitable for use in control panels, switchboards, and other electrical systems. The contactor's 2NC auxiliary contacts provide reliable switching capabilities, while its 120V AC coil ensures efficient operation. Suitable for use in a range of industries, including manufacturing, automation, and HVAC, this contactor offers a reliable and efficient solution for controlling electrical circuits. Its compact size and robust design make it an excellent choice for applications where space is limited.
Top product features:
- The IEC Miniature Magnetic Contactor has a reversing function available for motor control applications.
- It is rated for operation with DIN rail or plate mounting options.
- It is equipped with auxiliary contacts configured as 2 NC contacts.
Top product applications:
- Motor control applications
- Resistive load switching
- Lowto medium-power circuit control
The IEC Miniature Magnetic Contactor is a 3-pole reversing contactor from the TeSys K series. It uses a 120 V AC coil to switch low- to medium-power circuits for motor control and resistive loads. The device is rated for operation with DIN rail or plate mounting options and is compatible with screw clamp terminal connections. It is equipped with auxiliary contacts configured as 2 NC contacts.
- Action: Reversing function available for motor control applications
- - Poles: 3
- - Coil Voltage: 120 V AC
- - Series/Style: TeSys K, IEC
- - Mounting Style: DIN Rail, Plate
- - Electrical Connection: Compatible with screw clamp terminal connections
- - Auxiliary Contacts: Equipped
- Configuration: 2 NC contacts
- - Frequency: 50/60 Hz
- - IP Rating: IP20
- - Maximum Voltage Rating: Rated for operation up to 690 V AC within specified conditions
- - Rated Making Capacity: 110 A under specified test conditions
- - Withstand ratings: Based on standardized testing parameters and do not imply guaranteed performance under all conditions
- - Electrical durability: Based on standardized testing cycles and may vary with actual usage conditions
- - Mechanical durability: Based on standardized testing cycles and may vary with actual usage conditions
- - Rated Voltage: 690 V AC
- - Impedance: Typical impedance value measured under test conditions
- actual impedance may vary slightly in application
- - Impulse Withstand Voltage: Rated impulse withstand voltage according to standards
- does not guarantee protection against all transient events
- - Inrush VA / Hold VA / Max Operating Watts: Power consumption figures are nominal values based on standard tests and may differ during actual operation
- - Fuse Amps: 25 A (Power Circuit), 10 A (Signalling Circuit)
- - Net Weight: 0.39 kg
- - Width/Depth/Height: Width 2.5 in
- Overall Width 3.54 in
- Depth 3.6 in
- Overall Depth 2.24 in
- Height 2.5 in
- Overall Height 2.28 in
- - Enclosure: No Enclosure
- NEMA Enclosure Rating: No Enclosure
- - Fire Rating: UL 94 V1
- NF F 16-101
- NF F 16-102
- - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660
- - Signalling Circuit Frequency: Less Than 400 Hz
- - Shock Resistance: 10 G (11 ms) X axis (Closed)
- 15 G (11 ms) Y/Z axis (Closed)
- 6 G (11 ms) X axis (Open)
- 10 G (11 ms) Y/Z axis (Open)
- - Operating Temperature: Maximum 122 °F
- Minimum -13 °F
- - Reversing: Yes
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.70
- Package Width: 2.50
- Package Height: 2.60
- Package Weight: 0.81
