IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type MPN:LC1G5004EHEA

• The IEC Magnetic Contactor (TeSys Giga) is a 4-pole, electrically operated switching device used to control power circuits. Rated for operation within the specified voltage ranges (48V-130V AC/DC), auxiliary contacts configured as 1NC/1NO (2 total), and spring-type terminals mounted on a plate. It is a single-phase device, rated for operation within the specified voltage limits (1000V AC), conforming to IP20 ingress protection standards, and listed under the TeSys Giga series designation. The unit is rated for operation at frequencies of 50/60 Hz, (-13°F to 140°F) ambient temperatures, and is designed to withstand a specified number of operational cycles. It does not contain an integrated surge suppression device.

  - Item: IEC Magnetic Contactor (TeSys Giga), 4 poles, plate mounting

• - Coil Voltage: 48V-130V AC/DC
• - Auxiliary Contacts: 2 total (Form 1NC/1NO)
• - Embedded Surge Suppressor: No
• - Frequency: 50/60 Hz
• - Maximum Voltage Rating: Rated for operation within the specified voltage limits (1000V AC)
• - Full Load Amps - Inductive: 630 A
• Full Load Amps - Resistive: 700 A
• - Full Load Current - Inductive: 500 A
• Full Load Current - Resistive: 700 A
• - IP Rating: Conforms to IP20 ingress protection standards
• - Includes Auxiliary Contacts: Yes
• - Number of Auxillary Contacts: 2
• - Phase: Single
• - Series: TeSys Giga
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Mounting Style: Plate
• - Terminal Connection Type: Spring Type
• - Maximum Operating Temperature: 140 Degrees F
• Minimum Operating Temperature: -13 Degrees F
• - Overall Dimensions: Depth 4.8 in, Height 11.42 in, Width 7.28 in
