IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 4 P, Spring Type MPN:LC1G2254BEEA
Free Shipping
In Stock
The Schneider TeSys Giga IEC Magnetic Contactor is a reliable and efficient solution for controlling power circuits in various applications. Suitable for use in industrial, commercial, and residential settings, this 4-pole contactor operates within a wide temperature range and supports frequencies of 50/60 Hz. With a spring-type terminal connection and 1NC/1NO auxiliary contacts, it ensures smooth and secure switching. Ideal for use in HVAC systems, lighting control, and motor control, this contactor offers high mechanical durability and meets international standards for safety and performance. Its compact design and versatility make it an excellent choice for a wide range of applications.
Top product features:
- It has a coil voltage rating of 24–48V AC/DC, allowing it to operate within a wide range of power sources.
- It features two auxiliary contacts configured as 1NC/1NO, enabling the user to control and monitor the contactor's operation.
- It has a mechanical durability of approximately 8 million cycles, ensuring reliable and long-lasting performance under normal conditions.
Top product applications:
- Motor control circuits
- Industrial control systems
- Power distribution systems
An IEC Magnetic Contactor is an electrically operated switching device rated for controlling power circuits within the specified standards. It uses an electromagnetic coil to operate the contacts as specified by manufacturer instructions. This Schneider Electric unit is a 4-pole, plate-mount IEC magnetic contactor from the TeSys Giga series. The contactor has a coil voltage rating of 24–48V AC/DC and supports frequencies of 50/60 Hz
- it includes two auxiliary contacts configured as 1NC/1NO and features Spring Type terminal connections. The device does not include an embedded surge suppressor
- it has a maximum voltage rating of up to 1000V AC (per manufacturer specifications) and operates within temperatures ranging from -13°F to 140°F
- its mechanical durability is rated at approximately 8 million cycles under normal conditions.
- Coil Voltage: 24V-48V AC/DC
- - Auxiliary Contacts: 2 total (1NC/1NO)
- Includes Auxiliary Contacts: Yes
- - Auxiliary Contact Form: 1NC/1NO
- - Contactor Style: IEC
- - Poles: 4
- - Phase: Single
- - Mounting Style: Plate
- - Terminal Connection Type: Spring Type
- - IP Rating: IP20
- - Frequency: 50/60 Hz
- - Maximum Voltage Rating: 1000V AC
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Maximum Operating Temperature: 140 Degrees F
- - Minimum Operating Temperature: -13 Degrees F
- - Overall Dimensions (L x W x H): 7.6 in depth, 5.63 in width, 10.04 in height
- - Mechanical Operating Durability: 8000000
- - Embedded Surge Suppressor: No
- - Item: IEC Magnetic Contactor
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 63 days
- Minimum Order Quantity: 6
- Unit of Measure: EA
- Package Length: 15.16
- Package Width: 10.24
- Package Height: 9.84
- Package Weight: 14.09
