IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 3 P, Spring Type MPN:LC1G225BEEA
Free Shipping
In Stock
The TeSys Giga IEC Magnetic Contactor from Schneider Electric is a reliable and efficient solution for controlling power circuits in single-phase applications. With its 24V-48V AC/DC coil and 1NC/1NO auxiliary contacts, this 3-pole contactor is ideal for use in a variety of industries, including manufacturing, healthcare, and food processing. Its spring-type terminals and plate mounting make it easy to install and maintain. The TeSys Giga contactor also offers long-lasting performance with 8 million mechanical cycles and a temperature range of -13°F to 140°F, making it a great choice for applications where reliability and efficiency are crucial.
Top product features:
- The product has a 3-pole configuration for controlling power circuits.
- It features a 24V–48V coil (AC/DC) for versatile power supply compatibility.
- The device includes 2 auxiliary contacts configured as 1NC/1NO for additional control and feedback.
Top product applications:
- Power circuits
- Control systems
- Industrial automation
The IEC Magnetic Contactor from Schneider Electric is a 3-pole, IEC-standard electromagnetic switch used to control power circuits. It features a 24V–48V coil (AC/DC), 2 auxiliary contacts configured as 1NC/1NO, and spring-type terminals mounted on a plate. The device is rated for operation within the specified voltage range of 1000V AC
- operates at a frequency of 50/60 Hz
- intended for single-phase applications. It belongs to the TeSys Giga series and has an operating temperature range from -13°F to 140°F.
Key features
- - Item: IEC Magnetic Contactor
- Series: TeSys Giga
- Poles: 3
- Phase: Single
- - Coil voltage: 24–48 V AC/DC
- - Auxiliary contacts: 2 total
- Form: 1NC/1NO
- Includes auxiliary contacts: Yes
- - Terminal connections: Spring Type
- Mounting: Plate
- - Maximum voltage rating: 1000V AC
- Frequency: 50/60 Hz
- - IP rating: IP20
- - Mechanical durability: 8,000,000 cycles
- - Maximum operating temperature: 140°F
- Minimum operating temperature: -13°F
- - Full load current (inductive/resistive): 225 A / 330 A
- - Full load amps (inductive/resistive): 290 A / 330 A
- - Dimensions: Depth 7.6 in
- Height 10.04 in
- Width 4.25 in
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.16
- Package Width: 9.84
- Package Height: 9.06
- Package Weight: 11.62
