main product photo

IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type MPN:LC1G4004EHEA

Discount: See in Cart
Free Shipping
In Stock
Brand: Schneider
Part #: LC1G4004EHEA
UPC: 3606481922687
SKU
510-G510354423
$18,375.16 for Order Qty of 4
Regular Price $6,431.31 Special Price $4,593.79 Each

BBB Accredited - ResellerRatings Elite Member - SBA Service-Disabled Veteran-Owned Certified

Add to Wish List Add to Compare
IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type

The SCHNEIDER ELECTRIC IEC Magnetic Contactor is a reliable and efficient switching device for a wide range of applications. Ideal for use in industrial control systems, this 4-pole unit operates within a broad voltage range of 48V-130V AC/DC and features a spring-type terminal connection. With a mechanical durability of up to 8,000,000 cycles and a temperature rating of -13°F to 140°F, it withstands demanding conditions. Suitable for use in single-phase systems, this contactor is perfect for applications such as motor control, lighting, and heating systems, providing a high level of reliability and efficiency in a compact design.

Top product features:

  • IEC Magnetic Contactor is an electrically operated switching device rated for operation within the specified voltage and current ranges.
  • It is a 4-pole unit with a spring-type terminal connection.
  • It includes two auxiliary contacts configured as 1NC/1NO, rated for use with loads within the specified parameters.

Top product applications:

  • Industrial Automation
  • Motor Control Systems
  • Power Distribution Units

The SCHNEIDER ELECTRIC IEC Magnetic Contactor is an IEC-style, electrically operated switching device rated for operation within the specified voltage and current ranges. It is a 4-pole unit with a spring-type terminal connection and includes two auxiliary contacts configured as 1NC/1NO, rated for use with loads within the specified parameters.

- Item: IEC Magnetic Contactor

  • - Poles: 4
  • - Auxiliary Contacts: 2 (1NC/1NO)
  • - Coil Voltage: operates within the specified voltage range of 48V to 130V AC/DC
  • - Frequency: 50/60 Hz
  • - Phase: Single
  • - Terminal Connection Type: Spring Type
  • - Mounting Style: Plate
  • - Maximum Voltage Rating: 1000V AC
  • - IP Rating: IP20
  • - Includes Auxiliary Contacts: Yes
  • - Mechanical Operating Durability: designed for a mechanical durability of up to 8,000,000 cycles under normal operating conditions
  • - Maximum Operating Temperature: rated for operation within temperatures up to 140°F (60°C)
  • - Minimum Operating Temperature: rated for operation down to -13°F (-25°C) when used within specified environmental conditions
  • - Overall Dimensions: Depth 4.8 in, Height 11.42 in, Width 7.28 in
  • - Series: TeSys Giga
  • - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
  • - Full Load Amps - Inductive: 490 A
  • - Full Load Current - Inductive: 400 A
  • - Full Load Amps - Resistive: 550 A
  • - Full Load Current - Resistive: 550 A
  • - Embedded Surge Suppressor: No


    • Additional Information

    • Country of Origin: CN
    • Drop Ship Item: Yes
    • Blind Ship Eligible: No
    • LTL Freight Required: No
    • Lead Time: Ships in 63 days
    • Minimum Order Quantity: 4
    • Unit of Measure: EA
    • Package Length: 14.57
    • Package Width: 12.40
    • Package Height: 10.63
    • Package Weight: 24.14
    Product info last updated on January 21, 2026 9:00pm UTC Category: Industrial Electrical Controls and Automation
