IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 4 P, Spring Type MPN:LC1G3304EHEN
Free Shipping
In Stock
The Schneider TeSys Giga IEC Magnetic Contactor is a reliable and efficient switching device designed for control of power circuits in IEC-standard control panels. Suitable for a wide range of applications, including industrial automation, HVAC systems, and lighting control, this 4-pole device features 2 auxiliary contacts and a coil voltage range of 48V-130V AC/DC. With its spring-type terminal connections and plate mounting, it provides easy installation and maintenance. The TeSys Giga series offers high mechanical durability, with 8,000,000 cycles, and operates within a wide temperature range, making it an ideal choice for demanding industrial environments.
Top product features:
- The IEC Magnetic Contactor features 2 auxiliary contacts (1NC/1NO) for control and monitoring of power circuits.
- It has a coil voltage range of 48V-130V AC/DC for flexibility in power supply configurations.
- The unit has spring-type terminal connections for easy and secure wiring connections.
Top product applications:
- Industrial control panels
- Motor control circuits
- Power distribution systems
The IEC Magnetic Contactor is an electrically operated switching device that uses an electromagnetic coil to open or close contacts, enabling control of power circuits in IEC-standard control panels. This unit is a 4-pole device with 2 auxiliary contacts (1NC/1NO) and a coil voltage range of 48V-130V AC/DC. It features spring-type terminal connections and plate mounting, and is part of the TeSys Giga series. It is rated for operation within the specified voltage ranges, with IP20 protection, and is compatible with single-phase power supplies (as specified).
Key features
- - Item: IEC Magnetic Contactor (TeSys Giga series), 4 poles
- - Auxiliary contacts: 2 total (1NC/1NO)
- includes auxiliary contacts: Yes
- - Coil voltage: 48V-130V AC/DC
- - Contactor style: IEC
- Phase: Single
- - Mounting style: Plate
- Terminal connection type: Spring Type
- - Maximum voltage rating: 1000V AC
- - IP rating: IP20
- - Frequency: 50/60 Hz
- - Full Load Amps: Inductive 390 A
- Resistive 440 A
- - Full Load Current: Inductive 330 A
- Resistive 440 A
- - Mechanical durability: 8,000,000 cycles
- - Operating temperature: Min -13°F to Max 140°F
- - Dimensions: Depth 4.8 in
- Height 8.86 in
- Width 7.28 in
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 63 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.60
- Package Width: 12.20
- Package Height: 10.83
- Package Weight: 20.02
