IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type MPN:LC1G400EHEA
Free Shipping
In Stock
The Schneider IEC Magnetic Contactor is a versatile and reliable switching device ideal for a wide range of applications, including industrial control systems, motor control, and power distribution. With its 3-pole design and spring-type terminals, it offers efficient and safe operation within specified voltage and current ranges. The 1NC/1NO auxiliary contacts provide added functionality, while the TeSys Giga series ensures high-quality performance. Suitable for use in harsh environments, this contactor withstands temperatures from -13°F to 140°F and is compliant with major international standards, making it a trusted choice for industries requiring high reliability and efficiency.
Top product features:
- The IEC Magnetic Contactor has two auxiliary contacts configured as 1NC/1NO.
- It is rated for coil voltages between 48 V and 130 V AC/DC.
- It features spring-type terminals.
Top product applications:
- Industrial Automation
- Electrical Panel Building
- Power Distribution Systems
The IEC Magnetic Contactor is a 3-pole, IEC-style switching device rated for operation within specified voltage and current ranges. It is rated for coil voltages between 48 V and 130 V AC/DC, features spring-type terminals and plate mounting, and is part of the TeSys Giga series. The unit includes two auxiliary contacts configured as 1NC/1NO.
Key features:
- - Auxiliary contacts: 2 total (1NC/1NO)
- Includes auxiliary contacts: Yes
- - Coil voltages: rated for coil voltages between 48 V and 130 V AC/DC
- - Contactor style: IEC
- - Does not include an integrated surge suppression device
- - Frequency: 50/60 Hz
- - Full load current (inductive/resistive): rated for maximum continuous current of up to 550 A resistive load and 400 A inductive load under specified conditions
- - Full load amps (inductive/resistive): rated for maximum operational currents as specified
- actual performance may vary based on application conditions
- - IP rating: IP20
- - Maximum voltage rating: rated for operation at voltages up to 1000 V AC within the specified parameters
- - Operating temperature range: -13°F to 140°F
- designed to operate within ambient temperatures of -13°F to +140°F, depending on installation environment
- - Mechanical operating durability: 8000000
- - Mounting style: Plate
- - Number of poles: 3
- - Phase: Single
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Terminal connection type: Spring Type
- - Overall dimensions: Depth 4.8 in
- Height 11.42 in
- Width 5.51 in
Additional Information
- Country of Origin: US
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 63 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 14.57
- Package Width: 9.06
- Package Height: 12.20
- Package Weight: 19.71
