IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 3 P, Spring Type MPN:LC1G185BEEA
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient switching device for controlling power circuits in various applications. With its three-pole design and compatibility with 24-48 V AC/DC coils, it's ideal for use in industrial settings, such as motor control, lighting systems, and HVAC applications. The product's spring-type terminal connections and 1NC/1NO auxiliary contact arrangement ensure smooth operation and easy maintenance. Its IP20 protection rating and 8,000,000 cycle mechanical durability make it a durable choice for demanding environments. Suitable for use in a variety of settings, including commercial and industrial facilities, this contactor provides reliable power control and management.
Top product features:
- Three-pole, electrically operated switching device designed to control power circuits in accordance with IEC standards.
- Uses an electromagnetic coil to open or close contacts.
- Equipped with spring-type terminal connections for secure and efficient connections.
Top product applications:
- Industrial Automation
- Motor Control and Protection
- Power Distribution and Control
Schneider Electric’s IEC Magnetic Contactor is a three-pole, electrically operated switching device designed to control power circuits in accordance with IEC standards. It uses an electromagnetic coil to open or close contacts and is compatible with coils rated between 24-48 V AC/DC, with a 1NC/1NO auxiliary contact arrangement (2 total contacts), and equipped with spring-type terminal connections (specify as per product specifications). Rated for plate mounting as part of the TeSys Giga series, with operation up to 1000 V AC and IP20 protection rating.
- Item: IEC Magnetic Contactor
- - Series: TeSys Giga
- - Poles: 3
- - Phase: Single
- - Coil Voltage: 24-48 V AC/DC
- - Auxiliary Contact Form: 1NC/1NO
- - Auxiliary Contacts Included: Yes (2 total)
- - Terminal Connection Type: Equipped with spring-type terminal connections (specify as per product specifications)
- - Mounting Style: Plate
- - Maximum Voltage Rating: 1000 V AC
- - Frequency: 50/60 Hz
- - IP Rating: IP20
- - Mechanical Durability: 8,000,000 cycles
- - Maximum Operating Temperature: 140 Degrees F
- - Minimum Operating Temperature: -13 Degrees F
- - Overall Depth: 7.6 in
- - Overall Height: 10.04 in
- - Overall Width: 4.25 in
- - Embedded Surge Suppressor: No
- - Standards: Complies with applicable standards
- compliance does not imply suitability for all applications or environments
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 15.16
- Package Width: 9.84
- Package Height: 9.25
- Package Weight: 11.64
