Socket, General Purpose Relay, Square, 15 A, 8 Pins, Quick Connect MPN:8501RS42P14V20
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G4465045
Socket, General Purpose Relay, Square, 15 A, 8 Pins, Quick Connect
The Schneider General Purpose Relay is a versatile and reliable solution for a wide range of applications. With its square base shape and 8-pin quick-connect design, this relay is easily integrated into any system. Its DPDT contact form and 15A current rating make it suitable for controlling high-power devices, while its LED indicator and mechanical flag provide clear status feedback. Suitable for use in industrial control systems, machine automation, and building management, this relay is a reliable choice for applications requiring high power and flexibility, including HVAC, lighting control, and motor control.
Top product features:
- Has a DPDT contact form for switching multiple circuits
- Has an LED indicator for visual status monitoring
- Has a quick-connect electrical connection for easy setup and configuration
Top product applications:
- Industrial Automation Systems
- Motor Control Circuits
- Power Distribution Panels
General Purpose Relay, Base Shape Square, Coil Voltage 120V AC, Contact Form DPDT, Current Rating 15 A, Electrical Connection Quick-Connect, Flat Pin Width 0.18 in, Number of Pins 8, Pin Shape Flat, Sealing Enclosed, Status Indicator LED Indicator, Mechanical Flag, Contact Rating (AC) 15 A @ 120V, 15 A @ 277V, Contact Rating (DC) 15 A @ 28V, Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1/10 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.4 in, Body Height 2.09 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.00
- Package Width: 1.40
- Package Height: 1.30
- Package Weight: 0.10
Product info last updated on February 22, 2026 5:11pm UTC
Category: Industrial Electrical Controls and Automation
