IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type MPN:LC1G185EHEN

• Schneider Electric’s IEC Magnetic Contactor, TeSys Giga series, is an electrically operated switching device rated for use in applications compliant with IEC standards. It is a 3-pole device with two integrated auxiliary contacts (1NC/1NO) and a coil rated for operation within the specified voltage range (48–130 V AC/DC). The unit features Spring Type terminal connections and plate mounting compatible with standard IEC configurations.

  - Auxiliary contacts: 2 total (1NC/1NO)

• Includes Auxiliary Contacts: Yes
• Auxiliary Contact Form: 1NC/1NO
• - Coil voltage: 48V-130V AC/DC
• - Poles: 3
• Phase: Single
• Item: IEC Magnetic Contactor
• - Terminal connection type: Spring Type
• Mounting style: Plate
• - Rated for operation up to 1000 V AC as per specifications
• - IP rating: IP20
• - Frequency: 50/60 Hz
• - Embedded surge suppressor: No
• - Mechanical operating durability: tested to withstand up to 8,000,000 mechanical cycles under specified conditions
• - Temperature range: -13°F to 140°F (approximately -25°C to 60°C)
• - Full Load Amps: Inductive 250 A
• Resistive 305 A
• - Full Load Current: Inductive 185 A
• Resistive 305 A
• - Dimensions: Overall Height 7.6 in
• Overall Depth 7.6 in
• Overall Width 4.25 in
• - Series: TeSys Giga
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
