IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type MPN:LC1G330EHEN
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and versatile solution for control systems. With a 3-pole design and 48V-130V AC/DC coil voltage rating, it can be used in a variety of applications, including industrial automation, HVAC, and lighting control. The contactor's spring-type terminal connection and plate mounting make it easy to integrate into existing systems. Its robust design and high operating durability ensure reliable performance in demanding environments. Suitable for use in a range of industries, including manufacturing, construction, and energy management, this contactor provides a reliable and efficient solution for control system needs.
Top product features:
- IEC Magnetic Contactor is a 3-pole, electrically operated switch rated for operation within specified control system standards.
- It uses an electromagnetic coil to open or close the main contacts.
- It includes auxiliary contacts as specified, part of the TeSys Giga series with plate mounting.
Top product applications:
- Motor Control Circuits
- Industrial Automation Systems
- Control Panels
Schneider Electric IEC Magnetic Contactor is a 3-pole, electrically operated switch rated for operation within specified control system standards. It uses an electromagnetic coil to open or close the main contacts and includes auxiliary contacts as specified, part of the TeSys Giga series with plate mounting.
- Auxiliary contact form: 1NC/1NO
- Includes auxiliary contacts: Yes (2 total)
- - Number of Poles: 3
- Phase: Single
- - Coil Voltage: rated for coil voltages within the specified range
- - Contactor Style: IEC
- Mounting Style: Plate
- - Terminal Connection Type: Spring Type
- - Embedded Surge Suppressor: does not include an integrated surge suppressor
- - Frequency: 50/60 Hz
- - Maximum Voltage Rating: rated for use up to the specified voltage levels under normal conditions
- - IP Rating: IP20
- - Maximum/Minimum Operating Temperature: Max 140 Degrees F
- Min -13 Degrees F
- - Mechanical Operating Durability: tested for durability up to the specified number of cycles under standard testing conditions
- - Full Load Amps (Inductive/Resistive): 390 A / 440 A
- - Full Load Current (Inductive/Resistive): 330 A / 440 A
- - Overall Dimensions: Depth 4.8 in
- Height 8.86 in
- Width 5.51 in
- - Series: TeSys Giga
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.40
- Package Width: 8.86
- Package Height: 12.20
- Package Weight: 16.49
