IEC Miniature Magnetic Contactor, 1NO, 24V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0610B7

• The SCHNEIDER ELECTRIC IEC Miniature Magnetic Contactor is a 3-pole, non-reversing, 24 V AC coil device with 1 normally open auxiliary contact. It is rated for use in motor control applications within specified parameters, and is equipped with screw clamp terminals suitable for DIN rail or panel mounting.

  - Coil voltage: 24 V AC

• - Poles / main contacts: 3 poles
• 3 normally open main contacts
• auxiliary contact 1 NO
• - Auxiliary contact form: 1 NO
• - Reversing: Non-Reversing
• - Contactor style / series: IEC / TeSys K
• - Mounting: screw clamp terminals suitable for DIN rail or panel mounting
• - Maximum voltage / insulation: rated for operation up to 690 V AC
• complies with relevant insulation standards
• - Frequency: 50/60 Hz
• - Load ratings: rated load capacities under specified conditions (inductive and resistive loads)
• - Making/short-time capacity: rated making capacity and short-time withstand current according to standard testing procedures
• - Mechanical / electrical durability: tested durability under specified cycles, not a guarantee of lifespan under all conditions
• - Operating time: typical operating times based on test conditions, not guaranteed performance times
• - Hold / inrush: power consumption figures during hold and inrush states based on testing data
• hold 4.5 VA
• inrush 30 VA
• - Power / watts: maximum power ratings as per product specifications at designated voltages and load types
• - Weight: 0.18 kg
• - Dimensions: Width 1.73 in
• Depth 1.97 in
• Height 1.73 in
• Overall Height 2.28 in
• Overall Width 1.77 in
• - Degree of protection: No enclosure
• IP22
• - Fire / standards: UL 94 V1
• NF F 16-101
• NF F 16-102
• Standards include BS 5424, CSA, IEC 60947, UKCA, UL Listed, VDE 0660
• - Impulse withstand: 8 kV
• - Signalling / control: Signalling circuit 5 mA switching current
• 17 V switching voltage
• Insulation resistance > 10 MΩ (Signalling Circuit)
• - Terminal type: Screw Clamp
• - Tightening torque: 1.3 Nm
• - Environmental: Mercury Free, Toxic Heavy Metal Free
• - Voltage / short circuits: Rated Voltage 690 V AC
• Rated Making Capacity 110 A
• Rated Insulation 600/690 V
• - Reversing capability: No
