Socket, General Purpose Relay, Square, 15 A, 11 Pins, Faston Connector MPN:783XCXM4L-24D
Socket, General Purpose Relay, Square, 15 A, 11 Pins, Faston Connector
The Schneider General Purpose Relay is a versatile and reliable solution for a wide range of applications, including industrial control systems, HVAC, and lighting control. With a 15 A current rating and 11-pin Faston connector, it can handle high-power loads with ease. The relay's 3PDT contact form and LED status indicator provide clear and precise control, while the mechanical flag ensures reliable operation. Suitable for use in harsh environments, this relay is ideal for applications requiring high reliability and durability, such as in manufacturing, oil and gas, and pharmaceutical industries. Its compact design and fast shipping make it an ideal choice for any project.
Top product features:
- Square base shape
- 11-pin faston terminal for secure electrical connection
- 3PDT contact form for reliable switching and control
Top product applications:
- Industrial Automation Systems
- Automotive Wiring and Harnesses
- Medical Device Control Panels
General Purpose Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form 3PDT, Current Rating 15 A, Electrical Connection Faston Terminal, Flat Pin Width 0.187 in, Number of Pins 11, Status Indicator LED Indicator, Mechanical Flag, Contact Rating (AC) 10 A @ 151/277V, 15 A @ 120 to 277/120/150/250V, 7.55 A @ 250V (NC), Contact Rating (DC) 15 A @ 28V (NO), 7.55 A @ 28V (NC), Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 3/4 hp, Mounting Style Socket, Push-To-Test Method Lockable
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.20
- Package Width: 2.80
- Package Height: 1.50
- Package Weight: 0.14
Product info last updated on February 3, 2026 8:07pm UTC
Category: Industrial Electrical Controls and Automation
