IEC Miniature Magnetic Contactor, 1NO, 240V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0910U7
Free Shipping
In Stock
This IEC Miniature Magnetic Contactor from Schneider Electric is a reliable and efficient solution for motor control and resistive load applications. Its compact design and screw clamp terminals make it easy to integrate into a wide range of systems. With a 240V AC coil and 3-pole non-reversing operation, this contactor is suitable for use in industrial and commercial settings. Its features, including low inrush current and high making capacity, make it an ideal choice for applications where energy efficiency and reliability are paramount. It's perfect for use in control panels, motor starters, and other industrial automation applications.
Top product features:
- The SCHNEIDER ELECTRIC IEC Miniature Magnetic Contactor has a 3-pole, non-reversing design.
- It features 3 normally open main contacts and 1 auxiliary contact.
- It has screw clamp terminals for easy connection.
Top product applications:
- Motor control
- Resistive load control
- Industrial automation
The SCHNEIDER ELECTRIC IEC Miniature Magnetic Contactor is a 3-pole, non-reversing device with a 240 V AC coil (coil voltage). It is part of the TeSys K family and is rated for operation with motor control and resistive loads within specified parameters. It uses screw clamp terminals and has no enclosure or embedded surge suppressor. The contactor features 3 normally open main contacts and 1 auxiliary contact, rated according to specifications.
Key features
- - Coil voltage: 240 V AC
- Hold VA: 4.5 VA
- Inrush VA: 30 VA
- Watts loss: 1.3 W
- Operating times: 10 to 20 ms (energise NO close, de-energise NO open)
- - Poles/contacts: 3 poles
- 3 normally open main contacts
- Auxiliary contacts: 1 NO (1 auxiliary contact)
- - Reversing: Non-Reversing
- Frame/series: TeSys K / TeSys
- Contactor style: IEC
- - Electrical ratings: Max voltage 690 V AC
- Frequency 50/60 Hz
- Overvoltage CAT III
- - Current ratings: Full Load Amps – Inductive 9 A
- Full Load Amps – Resistive 20 A
- Rated Making Capacity 110 A
- Rated Breaking Capacity up to 110 A at multiple voltages
- - Standards: CSA, UKCA, UL Listed
- Enclosure: No Enclosure
- - Terminal: Screw Clamp
- Embedded surge suppressor: No
- Insulation resistance: Greater Than 10 MΩ (Signalling Circuit)
- - Dimensional footprint: Depth 1.97 in
- Height 1.73 in
- Width 1.73 in
- - Additional electrical characteristics: Inrush 30 VA
- Hold 4.5 VA
- Impedance 3 mΩ
- Shock resistance up to 10–15 G depending on axis/state
- Vibration resistance 4 G (Closed), 2 G (Open)
- - Environment and safety marks: Mercury Free, Toxic Heavy Metal Free
- Fire rating: UL 94 V1, NF F 16-101, NF F 16-102
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.50
- Package Width: 2.00
- Package Height: 2.50
- Package Weight: 0.35
