IEC Miniature Magnetic Contactor, 1NC, 24V AC, 3 P, Reversing, Screw Clamp MPN:LC2K0601B7
Free Shipping
In Stock
The IEC Miniature Magnetic Contactor from Schneider is a reliable and efficient solution for motor control applications. Suitable for use in a variety of settings, this contactor is designed to provide safe and reliable switching of motors and other electrical devices. Its compact design and screw clamp terminals make it easy to install and maintain, while its 24V AC coil and 3-pole reversing function enable smooth and efficient control of motor operations. Ideal for use in industrial and commercial settings, this contactor is a valuable addition to any electrical system, offering improved safety, efficiency, and reliability.
Top product features:
- It has 3 normally open main contacts for reliable switching.
- It is designed for motor control applications with a 24 V AC coil for efficient operation.
- It has a reversing function for bidirectional control of motors.
Top product applications:
- Motor control applications within specified electrical ratings
- Motor control circuits that require a reversing contactor
- General control applications that require a 3-pole contactor
The item is an IEC miniature magnetic contactor (Schneider Electric, TeSys K series). It is a 3-pole reversing contactor with a 24 V AC coil and 1 NC auxiliary contact, suitable for use in motor control applications within specified parameters.
Key features
- - Function: Reversing (further details should be provided separately)
- - Application: designed for motor control applications within specified electrical ratings
- - Coil Voltage: 24 V AC
- - Poles / Main contacts: 3 poles
- 3 normally open main contacts
- - Auxiliary contacts: 1 NC
- - Auxiliary contact configuration: 1NC
- - Electrical connection: Screw Clamp Terminals
- - Mounting: DIN Rail, Plate (Mounts On: Plate, Rail)
- - Series: TeSys K
- - Enclosure: open device
- appropriate enclosure should be used as per installation requirements
- - IP Rating: IP20
- - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660
- - Fire rating: fire ratings are based on testing standards
- actual performance depends on application conditions
- - Rated Voltage: rated for operation up to 690 V AC within specified conditions
- - Frequency: 50/60 Hz
- - Net Weight: 0.39 kg
- - Dimensions (W x H x D): 3.54 in x 2.28 in x 2.24 in
- - Environmental: environmental certifications are based on testing and compliance standards
- actual safety depends on proper usage and handling
- - Electrical durability: 1.3 Mcycles
- - Mechanical durability: 5 Mcycles
- - Rated Make Capacity: 110 A
- - Full Load Amps: Inductive 6 A
- Resistive 15 A
- - Impedance: 3 mΩ
- - Impulse withstand voltage: 8 kV
- - Rated insulation volts: 600/690 V
- - Max operating voltage: 690 V
Specifications recap
- - Series: TeSys K
- - Coil Voltage: 24 V AC
- - Poles / Main contacts: 3 poles
- 3 normally open main contacts
- - Auxiliary contacts: 1 NC
- - Electrical connection: Screw Clamp Terminals
- - Mounting: DIN Rail, Plate
- - Enclosure: open device
- appropriate enclosure should be used as per installation requirements
- - IP Rating: IP20
- - Rated Make Capacity: 110 A
- - Full Load Amps: Inductive 6 A
- Resistive 15 A
- - Impedance: 3 mΩ
- - Impulse withstand voltage: 8 kV
- - Rated insulation volts: 600/690 V
- - Max operating voltage: 690 V
Additional Information
- Country of Origin: FR
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.70
- Package Width: 2.70
- Package Height: 2.20
- Package Weight: 0.80
