IEC Magnetic Contactor, 1NC/1NO, 100V-250V AC/DC, 4 P, Spring Type MPN:LC1G5004KUEN
Free Shipping
In Stock
The Schneider Electric TeSys Giga IEC Magnetic Contactor is a versatile control device designed for single-phase electrical systems. With its 4-pole configuration and 100-250V AC/DC coil voltage, it provides reliable power switching in a variety of applications. The unit's 1NC/1NO auxiliary contacts and Spring Type terminal connection enable easy integration into complex systems. Suitable for use in industrial, commercial, and residential settings, this contactor offers a high level of mechanical durability, withstanding up to 8,000,000 cycles. Its compact design and robust construction make it an ideal choice for a range of applications, including lighting, HVAC, and machinery control.
Top product features:
- The IEC Magnetic Contactor features 100–250 V AC/DC coil voltage.
- The unit has two auxiliary contacts configured as 1NC/1NO.
- The contactor is designed to withstand up to 8,000,000 mechanical cycles.
Top product applications:
- Industrial Automation Systems
- Power Distribution Systems
- Control Panel Applications
The IEC Magnetic Contactor is a Schneider Electric control device (TeSys Giga) with 4 poles that uses an electromagnetic coil to switch power circuits. It features 100–250 V AC/DC coil voltage, two auxiliary contacts configured as 1NC/1NO, and a Spring Type terminal connection on a Plate mounting. The unit's maximum voltage rating is specified as 1000 V AC and it is designed for use in single-phase electrical systems within the specified parameters. It has an IP20 enclosure and is tested to withstand up to 8,000,000 mechanical cycles. It operates within the temperature range of -13°F to 140°F as per specifications.
- Coil voltage: 100-250V AC/DC
- - Auxiliary contacts: 2 (1NC/1NO)
- Includes auxiliary contacts: Yes
- - Poles: 4
- - Mounting: Plate
- Terminal connection: Spring Type
- - Contactor style: IEC
- Series: TeSys Giga
- - Maximum voltage rating: 1000V AC
- Phase: Single
- Frequency: 50/60 Hz
- - IP rating: IP20
- - Full load amps: Inductive 630 A
- Resistive 700 A
- - Full load current: Inductive 500 A
- Resistive 700 A
- - Maximum operating temperature: 140°F
- Minimum operating temperature: -13°F
- - Mechanical durability: 8,000,000 cycles
- - Dimensions: Depth 4.8 in
- Height 8.86 in
- Width 7.28 in
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- - Embedded Surge Suppressor: No
- - Includes Auxiliary Contacts: Yes
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 64 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 12.40
- Package Width: 12.20
- Package Height: 11.02
- Package Weight: 21.34
