IEC Magnetic Contactor, 1NC/1NO, 200V-500V AC/DC, 4 P, Spring Type MPN:LC1G5004LSEA

• The IEC Magnetic Contactor is a 4-pole, plate-mounted, single-phase device rated for operation within IEC-standard control systems. It contains an electromagnetic coil for switching contacts and has two auxiliary contacts (1NC/1NO). The unit features spring-type terminal connections, is rated for coil voltages between 200V and 500V (AC/DC), and is rated for a maximum voltage of up to 1000V AC. It belongs to the TeSys Giga series and does not include an embedded surge suppressor. Frequency support is 50/60 Hz, and the overall package accommodates a 50/60 Hz power environment.

  Key features

• - Auxiliary contacts: 2 total (1NC/1NO)
• - Coil voltage: is rated for coil voltages between 200V and 500V (AC/DC)
• - Contactor style: IEC
• - Embedded surge suppressor: No
• - Frequency: 50/60 Hz
• - Full Load Amps: Inductive 630 A
• Resistive 700 A
• - Full Load Current: Inductive 500 A
• Resistive 700 A
• - IP rating: IP20
• - Maximum voltage rating: is rated for a maximum voltage of up to 1000V AC
• - Mechanical operating durability: 8,000,000 cycles
• - Operating temperature: -13°F to 140°F
• - Mounting style: Plate
• - Number of poles: 4
• - Dimensions (L/H/W): 4.8 in × 11.42 in × 7.28 in
• - Phase: Single
• - Series: TeSys Giga
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Terminal connection type: Spring Type
