IEC Magnetic Contactor, 1NC/1NO, 24V-48V AC/DC, 4 P, Spring Type MPN:LC1G3304BEEA

• IEC Magnetic Contactor is an electrically operated switching device used to control power circuits. It employs electromagnetic actuation as specified and is rated for operation within the specified voltage ranges

• compatible with standard mounting configurations. This unit includes auxiliary contacts configured as 1NC/1NO per specifications and is part of the TeSys Giga series (product line).

  - Item: IEC Magnetic Contactor

• - Series: TeSys Giga
• - Contactor Style: IEC
• Phase: Single
• Number of Poles: 4
• Mounting Style: Plate
• Terminal Connection Type: Spring Type
• - Auxiliary Contacts: configured as 1NC/1NO per specifications
• - Coil Voltage: rated for coil voltages of 24V and 48V AC/DC within specified ranges
• - Embedded Surge Suppressor: Does not include a surge suppressor (no implied safety feature)
• - Frequency: 50/60 Hz
• - Full Load Amps - Inductive: 390 A
• Full Load Amps - Resistive: 440 A
• - Full Load Current - Inductive: 330 A
• Full Load Current - Resistive: 440 A
• - IP Rating: IP20
• - Maximum Voltage Rating: 1000V AC
• - Maximum Operating Temperature: approximately +60°C (140°F)
• Minimum Operating Temperature: approximately -25°C (-13°F)
• - Mechanical Operating Durability: 8,000,000 cycles
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Overall Dimensions: Depth 4.8 in
• Height 11.42 in
• Width 7.28 in
