IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type MPN:LC1G225EHEN

• The IEC Magnetic Contactor is a 3-pole, plate-mounted, spring-type device rated for operation within IEC standards. It includes two auxiliary contacts configured as 1NC/1NO and is energized by a coil rated 48–130 V (AC/DC). The unit is part of the TeSys Giga series, rated for operation at 50/60 Hz

• enclosed in an IP20-rated housing with a maximum voltage rating of 1000 V AC. It does not include surge suppression features and is suitable for single-phase applications within specified parameters.

  - Auxiliary contacts: 2 (1NC/1NO)

• - Coil voltage: 48–130 V AC/DC
• - Poles: 3
• - Mounting: Plate
• - Terminal connection: Spring Type
• - IP rating: IP20
• - Maximum voltage rating: 1000 V AC
• - Frequency: 50/60 Hz
• - Phase: Single
• - Series: TeSys Giga
• - Mechanical operating durability: 8,000,000 cycles
• - Maximum operating temperature: 140 °F
• - Minimum operating temperature: -13 °F
• - Full Load Amps – Inductive: 290 A
• Resistive: 330 A
• - Full Load Current – Inductive: 225 A
• Resistive: 330 A
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
