Socket, General Purpose Relay, Square, 15 A, 8 Pins, Quick Connect MPN:8501RS42V14
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3072815
Socket, General Purpose Relay, Square, 15 A, 8 Pins, Quick Connect
The Schneider General Purpose Relay is a versatile and reliable component for a wide range of applications. Its square shape and 8-pin configuration make it easy to integrate into existing systems, while its 15A current rating and DPDT contact form ensure efficient and safe switching. Suitable for use in industrial control systems, the relay features a quick-connect design for easy installation and a mechanical flag indicator for easy status monitoring. Its compact size and low power consumption make it ideal for use in applications such as lighting control, HVAC systems, and machinery control.
Top product features:
- Quick Connect electrical connection allows for easy installation and removal of the relay
- DPDT contact form provides two independent switching circuits
- Mechanical flag status indicator provides visual confirmation of the relay's status
Top product applications:
- Home Automation Systems
- Industrial Control Panels
- Automotive Electrical Systems
General Purpose Relay, Base Shape Square, Coil Voltage 24V AC, Contact Form DPDT, Current Rating 15 A, Electrical Connection Quick-Connect, Flat Pin Width 0.18 in, Number of Pins 8, Pin Shape Flat, Sealing Enclosed, Status Indicator Mechanical Flag, Contact Rating (AC) 15 A @ 120V, 15 A @ 277V, Contact Rating (DC) 10 A @ 28V, Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1/10 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.65 in, Body Height 1.07 in, Body Width 0.83 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.10
- Package Width: 1.30
- Package Height: 1.50
- Package Weight: 0.08
Product info last updated on February 18, 2026 3:21am UTC
Category: Industrial Electrical Controls and Automation
