Miniature Circuit Breaker, MULTI9 Series, 5A, 2 Pole, Not Rated, 5kA at 500V DC, C Curve MPN:MGN61525
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G3009237
Miniature Circuit Breaker, MULTI9 Series, 5A, 2 Pole, Not Rated, 5kA at 500V DC, C Curve
The MULTI9 Series Miniature Circuit Breaker is a reliable and efficient solution for distribution systems, providing protection against overcurrent and short circuits. This 5A, 2-pole device features a thermal-magnetic trip type and meets UL Type UL 1077 standards. With a maximum air rating of 5kA at 500V DC, it provides robust protection in a variety of applications, including commercial and industrial settings. The compact design allows for easy installation on DIN rail, making it ideal for use in distribution boards and panels. Its versatility and reliability make it a valuable addition to any electrical system.
Top product features:
- 5A current rating for safe and reliable operation
- C Curve protection for fast tripping in case of overload or short circuit
- Thermal Magnetic tripping mechanism for sensitive detection of faults and reduced false tripping
Top product applications:
- Distribution
- Thermal Magnetic Circuit Breaker
- DC Power Distribution
IEC Supplementary Protector, Amps 5 A, AC Voltage Rating Not Rated, Max. AIR Rating 5kA at 500V DC, Series C60H-DC, Curve Type C, DC Voltage Rating 500V DC, Number of Poles 2, Phase 1, Circuit Breaker Actuator Toggle, Circuit Breaker Mounting Style DIN Rail, Meets UL Type UL 1077, Terminal Connection Lug, Trip Type Thermal Magnetic, Application Distribution, Min. Wire Size 18 AWG, Max. Wire Size 4 AWG, Length 3.19 in, Width 1.42 in, Depth 2.87 in, Residual Current Type A
Additional Information
- Country of Origin: CN
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 89 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.20
- Package Width: 3.00
- Package Height: 1.40
- Package Weight: 0.50
Product info last updated on January 13, 2026 1:00pm UTC
Category: Circuit Protection
