Socket, General Purpose Relay, Square, 15 A, 5 Pins, Quick Connect MPN:8501RS41V14
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2845053
Socket, General Purpose Relay, Square, 15 A, 5 Pins, Quick Connect
The Schneider General Purpose Relay is a versatile and reliable solution for a wide range of applications. Its square base shape and quick-connect flat pins make it easy to install and integrate into any system. With a current rating of 15A and contact ratings for AC and DC, this relay can handle a variety of tasks, from controlling small motors to managing high-power loads. Its compact size and enclosed sealing make it suitable for use in harsh environments, and the mechanical flag status indicator provides visual confirmation of relay operation. Ideal for use in industrial control systems, automation, and more.
Top product features:
- Square shape allows for easy installation and mounting in tight spaces.
- Quick-Connect electrical connection enables fast and secure connection of wires.
- SPDT contact form provides a single-pole, double-throw switching capability.
Top product applications:
- Automotive Electrical Systems
- Industrial Automation and Control Systems
- Home and Commercial Lighting Control Systems
General Purpose Relay, Base Shape Square, Coil Voltage 24V AC, Contact Form SPDT, Current Rating 15 A, Electrical Connection Quick-Connect, Flat Pin Width 0.189 in, Number of Pins 5, Pin Shape Flat, Sealing Enclosed, Status Indicator Mechanical Flag, Contact Rating (AC) 15 A @ 120V, 15 A @ 277V, Contact Rating (DC) 15 A @ 28V, Horsepower @ 120V AC 1/2 hp, Horsepower @ 240V AC 1/10 hp, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.62 in, Body Height 2.07 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.00
- Package Width: 1.40
- Package Height: 1.00
- Package Weight: 0.06
Product info last updated on January 13, 2026 1:45pm UTC
Category: Industrial Electrical Controls and Automation
