Socket, General Purpose Relay, Square, 5 A, 14 Pins, Quick Connect MPN:8501RSD34V53
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G2745215
Socket, General Purpose Relay, Square, 5 A, 14 Pins, Quick Connect
This General Purpose Relay from Schneider is a reliable and versatile solution for a wide range of applications. Its hermetically sealed design ensures long-lasting performance in harsh environments, while its 14-pin quick-connect interface simplifies installation and maintenance. With a current rating of 5A and a contact form of 4PDT, this relay is suitable for various control circuits, including lighting, heating, and ventilation systems. Its compact size and low profile make it ideal for use in tight spaces, such as industrial control panels and automation systems. Its 24V DC coil voltage and AC ratings of 120/240V make it a flexible choice for diverse applications.
Top product features:
- Hermetically sealed design provides a secure and reliable environment for the relay's internal components.
- Quick-connect electrical connection allows for easy and fast connection and disconnection of wires.
- 4PDT contact form enables the relay to control multiple circuits or devices with a single coil activation.
Top product applications:
- Industrial Automation
- Automotive Systems
- Medical Equipment Control Panels
Hermetically Sealed Relay, Base Shape Square, Coil Voltage 24V DC, Contact Form 4PDT, Current Rating 5 A, Electrical Connection Quick-Connect, Flat Pin Width 0.09 in, Number of Pins 14, Pin Shape Flat, Sealing Hermetically Sealed, Status Indicator No Indicator, Contact Rating (AC) 5 A @ 120/240V, Contact Rating (DC) 5 A @ 28V, Horsepower @ 120V AC Not Rated, Horsepower @ 240V AC Not Rated, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 1.07 in, Body Height 1.37 in
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.10
- Package Width: 1.30
- Package Height: 1.00
- Package Weight: 0.17
Product info last updated on January 13, 2026 1:55pm UTC
Category: Industrial Electrical Controls and Automation
