IEC Miniature Magnetic Contactor, 1NO, 110V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K0610F7
Free Shipping
In Stock
The Schneider Electric IEC Miniature Magnetic Contactor is a versatile and reliable device for motor control applications. Suitable for use in various industries, this 3-pole, non-reversing contactor features screw clamp terminals and a compact design that mounts easily on DIN rails or plates. With a 110V AC coil and 3 normally open main contacts, it provides efficient and safe switching for loads up to 6A inductive and 15A resistive. Ideal for use in motor control circuits, this contactor offers a reliable and cost-effective solution for a range of applications, including industrial automation, HVAC, and more.
Top product features:
- The contactor has three normally open main contacts for reliable circuit control.
- The contactor uses screw clamp terminals for easy and secure wiring connections.
- The contactor is designed for non-reversing action, allowing for precise control of motor direction.
Top product applications:
- Motor Control
- Non-Reversing Applications
- General Purpose Switching
The Schneider Electric IEC Miniature Magnetic Contactor is a 3-pole, non-reversing, electrically operated switching device (TeSys series) with a 110 V AC coil. It has three normally open main contacts and one normally open auxiliary contact, and uses screw clamp terminals for wiring. Suitable for motor control applications within specified parameters, it mounts on DIN rails or plates and ships without an enclosure
- the user should provide an appropriate enclosure as needed.
- Action: Non-Reversing
- - Application: Motor Control
- - Coil Voltage: 110 V AC
- - Main Contacts: 3 NO
- - Auxiliary Contacts: 1 NO (Includes Auxiliary Contacts)
- - Frame/Series: TeSys
- - Contactor Style: IEC
- - Mounting: DIN Rail, Plate
- - Electrical Connection: Screw Clamp Terminals
- - Enclosure: No Enclosure
- - IP Rating: IP22
- - Frequency: 50/60 Hz
- - Rated Voltage: Rated for operation at voltages up to 690 V AC within specified conditions
- - Inrush VA: 30 VA
- - Hold VA: 4.5 VA
- - Tightening Torque: 0.8–1.3 Nm
- - Net Weight: 0.18 kg
- - Dimensions (W x H x D): 1.77 in x 2.28 in x 2.24 in
- - Mechanical Durability: 10 Mcycles
- - Electrical Durability: 1.3 Mcycles
- - Full Load Current (Inductive/Resistive): Rated for use with loads up to 6 A (inductive) and 15 A (resistive) under specified conditions
- - Rated Making Capacity: Has a rated making capacity of up to 110 A under standard test conditions
- - Standards: BS 5424, CSA, IEC 60947, NF C 63-110, UKCA, UL Listed, VDE 0660
- - Includes Auxiliary Contacts: Yes
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 2.40
- Package Width: 2.00
- Package Height: 2.60
- Package Weight: 0.40
