IEC Magnetic Contactor, 1NC/1NO, 48V-130V AC/DC, 3 P, Spring Type MPN:LC1G225EHEA
Free Shipping
In Stock
The Schneider Electric IEC Magnetic Contactor is a reliable and efficient switching device designed for use in control panels. Its 3-pole configuration and spring-type terminals make it ideal for applications requiring high current ratings and easy installation. Suitable for use in a wide range of voltage conditions, from 48-130V AC/DC, this contactor is perfect for industrial automation, HVAC systems, and other applications where high reliability is crucial. With a mechanical operating durability of 8,000,000 cycles and an operating temperature range of -13°F to 140°F, this contactor provides long-lasting performance in demanding environments.
Top product features:
- 3-pole coil-operated switching device
- 2 auxiliary contacts configured as 1NC/1NO
- Spring-type terminals for secure connections
Top product applications:
- Motor Control Circuits
- Industrial Automation Systems
- Control Panels
Schneider Electric IEC Magnetic Contactor (TeSys Giga) is a 3-pole, coil-operated switching device with two auxiliary contacts configured as 1NC/1NO. It features spring-type terminals, a coil voltage range of 48–130 V AC/DC, and an IEC design rated for operation within the specified voltage ranges and compatible with plate mounting in control panels.
- Item: IEC Magnetic Contactor
- Series: TeSys Giga
- Poles: 3
- Phase: Single
- Coil Voltage: 48–130 V AC/DC
- Auxiliary Contacts: 2 (1NC/1NO)
- Embedded Surge Suppressor: No
- Terminal Connection Type: Spring Type
- Maximum Voltage Rating: rated for operation up to 1000 V AC within specified conditions
- IP Rating: IP20
- Mounting Style: Plate
- Frequency: 50/60 Hz
- Full Load Amps – Inductive: 290 A
- Full Load Amps – Resistive: 330 A
- Full Load Current – Inductive: 225 A
- Full Load Current – Resistive: 330 A
- Mechanical Operating Durability: 8,000,000 cycles
- Operating Temperature Range: -13°F to 140°F
- Depth x Height x Width: 7.6 in x 10.04 in x 4.25 in
- Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
- Includes Auxiliary Contacts: Yes.
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 14.96
- Package Width: 9.06
- Package Height: 9.84
- Package Weight: 11.64
