IEC Magnetic Contactor, 1NC, 230V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1K1201P7
Discount: See in Cart
Free Shipping
In Stock
Free Shipping
In Stock
SKU
510-G210080936
IEC Magnetic Contactor, 1NC, 230V AC, 3 P, Non-Reversing, Screw Clamp
The TeSys K IEC Magnetic Contactor is a reliable and efficient solution for controlling electrical circuits in a variety of applications. With a 1NC auxiliary contact form and non-reversing functionality, this contactor is ideal for use in industrial automation, motor control, and power distribution systems. Its 230V AC coil voltage and 690V AC maximum voltage rating make it suitable for a range of applications, from small machines to large industrial equipment. The contactor's DIN rail and plate mounting style and screw clamp terminal connection make it easy to integrate into existing systems, providing a high level of reliability and performance.
Top product features:
- IEC Magnetic Contactor has 3 poles for handling multiple circuit connections.
- IEC Magnetic Contactor includes 1NC auxiliary contact for added functionality.
- IEC Magnetic Contactor has a screw clamp terminal connection type for secure and easy wiring.
Top product applications:
- Industrial Automation Systems
- Motor Control Circuits
- Power Distribution Systems
- Item: IEC Magnetic Contactor
- Series: TeSys K
- Poles: 3
- Auxiliary contact form: 1NC
- Includes Auxiliary Contacts: Yes
- Reversing: Non-Reversing
- - Coil Voltage: 230V AC
- - Maximum Voltage Rating: 690V AC
- - Frequency: 50/60 Hz
- - Mounting Style: DIN Rail, Plate
- Terminal Connection Type: Screw Clamp
- - IP Rating: IP20
- - Does not include built-in surge suppression features
- - Insulation Resistance: meets insulation resistance standards as specified in applicable standards
- - Electrical Operating Durability: 1,300,000 (AC-3), 1,300,000 (AC-3e), 300,000 (AC-1)
- - Mechanical Operating Durability: 10,000,000
- - Full Load Amps - Inductive/Resistive: 12 A / 20 A
- - Full Load Current - Inductive/Resistive: 12 A / 20 A
- - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, GB/T 14048.4, JIS C8201-4-1, UL 60947-4-1
- - Overall Dimensions: Depth 2.24 in
- Height 2.28 in
- Width 1.77 in
Additional Information
- Country of Origin: FR
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 61 days
- Minimum Order Quantity: 50
- Unit of Measure: EA
- Package Length: 2.56
- Package Width: 2.36
- Package Height: 1.85
- Package Weight: 0.39
Product info last updated on January 13, 2026 2:03pm UTC
Category: Industrial Electrical Controls and Automation
