Air Valve, 24V, 1/4" Compression, 0.59 scfm MPN:AL-190
Air Valve, 24V, 1/4" Compression, 0.59 scfm
The Schneider Air Valve is a reliable and efficient solution for controlling air flow in a variety of applications. With a 24V solenoid and 1/4in compression, this valve is perfect for use in pneumatic systems, air-powered tools, and other air-mediated processes. Its low air consumption of 0.59 cfm makes it an energy-efficient choice, while its operating pressure of up to 30 psi ensures reliable performance. Suitable for use in temperatures between 32°F and 130°F, this valve is ideal for applications in manufacturing, automation, and HVAC systems, where precise air flow control is critical.
Top product features:
- 24V operation allows the valve to be powered by a standard electrical supply.
- The valve has a normally closed port connection and a normally open port connection, allowing for automatic shutoff and controlled airflow.
- The valve features a solenoid design, enabling fast and reliable actuation of the airflow.
Top product applications:
- Air-powered pneumatic tools such as air hammers, riveters, and grinders
- Automated factory production lines that require air-powered actuators
- Medical equipment that uses air pressure to operate pneumatic components
Solenoid Air Valve, Air Consumption 0.59 cfm, Body Material Plastic, Common Port Connection Size 1/4 in, Electrical Lead Length 18 in, For Media Air, Frequency 60 Hz, Mounting Style Bracket Mount, Normally Closed Port Connection Size 1/4 in, Normally Open Port Connection Size 1/4 in, Number of Port Connections 3, Operating Pressure - Maximum 30 psi, Operating Temperature - Maximum 130 Degrees F, Operating Temperature - Minimum 32 Degrees F, Overall Depth 1 5/8 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: Yes
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 10 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 1.00
- Package Width: 1.00
- Package Height: 1.00
- Package Weight: 1.30
Product info last updated on February 1, 2026 8:04am UTC
Category: HVACR and Appliance Controls
