Air Valve, 24V, 1/4" Barb MPN:AL-180
Air Valve, 24V, 1/4" Barb
The Schneider Solenoid Air Valve is a reliable and efficient solution for controlling air flow in various industrial applications. This 24V valve features a 1/4in barb connection and consumes 0.3 cfm of air, making it ideal for use in pneumatic systems. Its plastic body and junction box enclosure ensure durability and easy installation. With a maximum operating pressure of 30 psi and temperature range of 40-130°F, this valve is suitable for a wide range of applications, including manufacturing, automation, and HVAC systems. Its compact size and fast shipping make it a convenient choice for businesses and industries.
Top product features:
- Air consumption of 0.3 cfm
- Solenoid operation with a 24V power requirement
- Normally closed and normally open port connections for flexible system configuration
Top product applications:
- Air Compressor System: The 24V solenoid air valve can be used to control airflow in an air compressor system, allowing for precise regulation of air pressure and flow rate.
- Pneumatic Tool Control: This air valve can be used to control the operation of pneumatic tools, such as air wrenches and air hammers, by regulating the airflow to the tool.
- Medical Device Application: The solenoid air valve can be used in medical device applications, such as ventilators and anesthesia machines, where precise control of air flow is critical.
Solenoid Air Valve, Air Consumption 0.3 cfm, Body Material Plastic, Common Port Connection Size 1/4 in, Electrical Lead Length 18 in, Enclosure Type Junction Box, For Media Air, Frequency 60 Hz, Installation Orientation Vertical, Normally Closed Port Connection Size 1/4 in, Normally Open Port Connection Size 1/4 in, Number of Port Connections 3, Operating Pressure - Maximum 30 psi, Operating Temperature - Maximum 130 Degrees F, Operating Temperature - Minimum 40 Degrees F, Overall Depth 1 3/8 in
Additional Information
- Country of Origin: MX
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 4.40
- Package Width: 3.80
- Package Height: 1.40
- Package Weight: 0.50
Product info last updated on February 12, 2026 2:31pm UTC
Category: HVACR and Appliance Controls
