Socket, General Purpose Relay, Square, 15 A, 8 Pins, Faston Connector MPN:782XBXM4L-24A
The SE Relays 782 series plug-in general purpose relay is a robust and reliable solution for automation panels and controls. Its square base mounting design provides excellent structural support, while the clear cover with LED indication and locking push button ensures easy operation and maintenance. With 15A resistive contacts and a nominal coil voltage of 24VAC, this relay is ideal for controlling separate circuits. Its gold flashed contact DPDT configuration reduces oxidation and increases shelf life. Suitable for applications such as industrial automation, machine control, and building management systems, this relay offers a reliable and efficient solution for a wide range of uses.
Top product features:
- Gold flashed contact DPDT configuration reduces oxidation and increases shelf life, giving simultaneous control of separate circuits.
- Mechanical standard flag indicator displays the relay status during testing or operation.
- Socket-mounting option with blade terminal style simplifies installation and maintenance.
Top product applications:
- Automation panels
- Controls
- Industrial equipment
The SE Relays 782 series, plug-in general purpose relay offers robust and historically proven square base mounting relay platform that provides excellent structural support with clear cover with LED indication and locking push button. Contacts rated as 15A resistive at 277VAC, motor 1/2hp at 120VAC, 1hp at 277VAC with nominal coil voltage 24VAC , makes relay to be an ideal choice for automation panels and controls. Gold flashed contact DPDT configuration reduces oxidation and increases shelf life, gives simultaneous control of separate circuits. Socket-mounting option, blade terminal style simplified installation and maintenance and using of protection modules, hold-down clips, and other accessories. Mechanical standard flag indicator displays the relay status during testing or operation.
Additional Information
- Country of Origin: CN
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 3.50
- Package Width: 2.80
- Package Height: 1.30
- Package Weight: 0.09
