IEC Magnetic Contactor, 1NC/1NO, 200V AC, 3 P, Non-Reversing, Screw Clamp MPN:LC1D50AL7
Free Shipping
In Stock
This IEC Magnetic Contactor from Schneider Electric is a reliable and efficient solution for motor control and resistive load applications in control panels. Its non-reversing action ensures safe and consistent operation, while its 200V AC coil and 3-pole design provide flexible and reliable switching. With 2 auxiliary contacts and 3 main contacts, this contactor offers a range of control options and is suitable for use in a variety of industrial settings, including manufacturing, HVAC, and water treatment. Its compact design and DIN rail compatibility make it easy to integrate into existing systems.
Top product features:
- IEC Magnetic Contactor has a non-reversing action.
- It is suitable for motor control and resistive load applications.
- It has 3 normally open main contacts.
Top product applications:
- Motor control applications
- Resistive load applications
- Control circuits for power distribution systems
Schneider Electric IEC Magnetic Contactor, 3-pole, non-reversing, with a 200 V AC coil and 1 normally open/1 normally closed auxiliary contacts (2 auxiliary contacts total). It is an IEC-style magnetic contactor rated for switching power circuits for motor control and resistive loads, suitable for installation in control panels with standardized sizing.
- Action: Non-Reversing
- - Poles: 3
- Phase: Three
- - Coil Voltage: 200 V AC
- - Auxiliary Contacts: 2 total (1NO/1NC)
- - Main Contacts: 3 NO
- - Contactor Style: IEC
- - Application: Suitable for motor control and resistive load applications (see specifications).
- - Electrical Connection: Control Circuit: Screw Clamp Terminals
- Power Circuit: EverLink BTR Screw Connectors
- - Includes: Power connections and protective cover as specified.
- - IP Rating / Enclosure: Rated at IP20
- enclosure not included.
- - Mounting Style / Mounts On: Compatible with DIN rail or mounting plates as specified.
- - Dimensions: Dimensions are provided as approximate measurements based on product specifications.
- - Net Weight: Net weight is approximately 0.855 kg based on manufacturing data.
- - Rated Voltage: Rated voltage ranges are specified within the product's operational ratings (see specifications).
- - Series: Series designation only
- does not imply performance guarantees beyond listed standards.
- - Reversing: Reversing function not included or supported by this model specification.
- - Overvoltage Category: Overvoltage category classification per standards but does not guarantee suitability under all conditions outside specified ratings.
- - Frequency: Frequency compatibility within standard operating ranges (see specifications).
- - Rated Making Capacity: Capacities are rated values based on testing conditions but do not imply continuous or guaranteed operation under all circumstances.
- - Rated Short-Time Withstand Current: 400 A (40°C, 10 s)
- 810 A (40°C, 1 s)
- - Mechanical Durability: 6 Mcycles
- - Electrical Durability: 1,100,000 to 1,450,000 cycles
- - Standards: EN 60947-4-1, EN 60947-5-1, UL 508, UL Listed, CSA, CSA C22.2 No 14
- - Fire Rating: UL 94 V1
- - Holding/Coil VA: 13 VA (60 Hz, 20°C)
- 15 VA (50 Hz, 20°C)
Additional Information
- Country of Origin: ID
- Drop Ship Item: No
- Blind Ship Eligible: No
- LTL Freight Required: No
- Lead Time: Ships in 1 days
- Minimum Order Quantity: 1
- Unit of Measure: EA
- Package Length: 6.00
- Package Width: 5.40
- Package Height: 2.50
- Package Weight: 2.08
