IEC Magnetic Contactor, 1NC/1NO, 200V-500V AC/DC, 4 P, Spring Type MPN:LC1G1854LSEA

• The IEC Magnetic Contactor is an electrically operated switching device rated for operation within the specified IEC standards. It uses an electromagnetic coil to open or close the main contacts, enabling switching of loads such as motors and lighting. This 4-pole, plate-mounted unit from the TeSys Giga family is constructed to meet IEC style specifications, rated for coil voltages between 200V and 500V AC/DC, with spring-type terminals, and includes auxiliary contacts configured as 1NC/1NO. It does not include an integrated surge suppression device and has an IP20 rating.

  - Item: IEC Magnetic Contactor

• - Series: TeSys Giga
• - Contactor Style: IEC
• - Phase: Single
• - Poles: 4
• - Auxiliary Contacts: 2 (1NC/1NO)
• Includes Auxiliary Contacts: Yes
• - Coil Voltage: 200V-500V AC/DC
• - Mounting Style: Plate
• - Terminal Connection Type: Spring Type
• - Maximum Voltage Rating: 1000V AC
• - Frequency: 50/60 Hz
• - IP Rating: IP20
• - Full Load Amps (Inductive/Resistive): 250 A / 305 A
• - Full Load Current (Inductive/Resistive): 185 A / 305 A
• - Mechanical Operating Durability: 8,000,000 cycles
• - Maximum Operating Temperature: 140 Degrees F
• - Minimum Operating Temperature: -13 Degrees F
• - Overall Dimensions: 7.6 in depth x 10.04 in height x 5.63 in width
• - Standards: CSA C22.2 No 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-5-1, JIS C8201-4-1, JIS C8201-5-1, UL 60947-4-1
• - Integrated Surge Suppression Device: No
